http2lmtp

Recieve HTTP-enveloped mail and route it as LMTP to local Unix socket.

Cloudflare Email Workers can only reach a cf tunnel over HTTP, so the message has to be wrapped in an HTTP request to get through. On the server side, http2lmtp unwraps it and hands it to an LMTP-capable MDA such as Dovecot.

Quickstart

cat <<EOF >/etc/http2lmtp.env
INGEST_TOKEN=$(uuidgen)
LMTP_SOCK=/var/run/dovecot/lmtp
LISTEN_ADDR=127.0.0.1:1234
RUST_LOG=info
EOF

cargo build --release
cp target/release/http2lmtp /usr/local/bin/
cp http2lmtp.service /etc/systemd/system/
systemctl daemon-reload
systemctl enable --now http2lmtp.service

Protocol

POST /inject

Header	Required	Description
`authorization`	yes	`Bearer <INGEST_TOKEN>`
`content-type`	no	`message/rfc822`
`x-envelope-from`	no	SMTP `MAIL FROM` address
`x-envelope-to`	no	SMTP `RCPT TO` address, unless `LMTP_RCPT` is set

The body is the raw RFC 5322 message.

curl -i -X POST http://127.0.0.1:1234/inject \
  -H "authorization: Bearer $INGEST_TOKEN" \
  -H "content-type: message/rfc822" \
  -H "x-envelope-from: [email protected]" \
  -H "x-envelope-to: [email protected]" \
  --data-binary @message.eml

Status	Meaning
`204`	Delivered.
`401`	Missing or invalid token.
`422`	LMTP rejected the message permanently (5xx). Do not retry.
`503`	LMTP unreachable or rejected temporarily (4xx). Retry later.

Environment

All configuration is read from the environment at startup. Missing required variables cause the process to exit before binding.

Variable	Required	Default	Description
`INGEST_TOKEN`	yes	—	Shared secret. Requests must carry `Authorization: Bearer <token>`. Compared in constant time.
`LMTP_SOCK`	yes	—	Path to the LMTP unix socket, e.g. `/var/run/dovecot/lmtp`. The process must have write access to it.
`LISTEN_ADDR`	no	`127.0.0.1:8080`	Address and port for the HTTP listener.
`LMTP_RCPT`	no	—	Deliver every message to this single recipient instead of the address in `x-envelope-to`. The original recipient is preserved as an `X-Original-To:` header. Unset: the envelope recipient is passed through as-is.
`RUST_LOG`	no	—	Log filter, e.g. `http2lmtp=info`. Standard `tracing-subscriber` syntax.

Example

INGEST_TOKEN=$(openssl rand -base64 32)
LMTP_SOCK=/var/run/dovecot/lmtp
LISTEN_ADDR=127.0.0.1:1234
LMTP_RCPT=[email protected]
RUST_LOG=http2lmtp=info

Example client (cloudflare workers)

export default {
  async email(message, env, ctx) {
    const res = await fetch("https://example.com/inject", {
      method: "POST",
      headers: {
        "authorization": `Bearer ${env.INGEST_TOKEN}`,
        "content-type": "message/rfc822",
        "x-envelope-from": message.from,
        "x-envelope-to": message.to,
      },
      body: message.raw,
    });

    if (!res.ok) {
      const detail = await res.text().catch(() => "");
      throw new Error(`ingest ${res.status} ${detail.slice(0, 200)}`);
    }
  },
};
